Powertex

POWERTEX Chain bags are durable and designed to be easily mounted to chain blocks. They can contain up to 10 meter of chains.

  • Universal - Fits many brands and models of chain hoists in the market
  • Easy to mount without dismantling the hoist
  • Comes in two different sizes
  • The chain bags can be combined with POWERTEX Chain Block – both Blackline BK and standard S1 and S2 versions.
    Blackline BK products are suitable to be used in theatres and entertainment industry.
  • Material: PVC-coated canvas steel frame/holding pillars.
  • Finish: Black.
    POWERTEX Chain bag for chain blocks with mounting brackets
    POWERTEX Chain block with chain bag
    Chain bag POWERTEX dimension drawing Chain bag POWERTEX dimension drawing
    Part Code For hoist A
    mm
    B
    mm
    C
    mm
    D
    mm
    E
    mm
    CAD
    16.10PCB100300 Chain Block PCB 0,5 t 360 120 90 47 20
    16.10PCB100301 Chain Block PCB 1 t 412 145 90 47 27
    16.10PCB100302 Chain Block PCB 2 t 426 145 110 60 35

    Download CAD

    Download CAD by choosing the desired product from the table above and the format from the menu below. Click "Get CAD" and after the load reaches 100% you can click on the download icon to download it. Please note that CAD drawings are only available if the icon at the right side of the table above is colored and not grayed out.

    To download CAD files, you must provide a valid e-mail address
